Home> Product> Cotton processing> Saw Gin Series>
MYZ215-14.8 Saw Gin
Output: 2000-3000kg/h
Structural mass: 12000kg
Overall dimensions mm (length × width × height): 4720 × 3688 × 3558.5mm
Equipped power: 108.8kw
Number of saw blades: 215Pcs
Saw blade pitch: 14.8mm
Saw blade diameter: 406mm
Brush barrel diameter: 450mm
Seed cotton import size (length × width): 3328 × 320mm
Lint export size (length × width): 3310 × 120mm

Message

Product details

1. New type cotton extracting and feeding structure, high impurity removal efficiency , continuous and even cotton feeding without flying dust.
2. New work chamber is more conducive to the operation of cotton roll, easy to control the fiber leftover rate of ginned seeds.
3. PLC program automatically and accurately adjusts the parameters of work chamber through servo motor and improves lint quality and equipment efficiency.
4. Touch screen control, man-machine dialogue and easy operation.
5. Middle chamber transfer technology is adopted to remove cotton stalks, effectively prevent cotton roll from stopping,it is suitable to process machine-harvestedcotton and improves the output.
6. Double push rod control for chamber opening and closing , stable and reliable.
7. Streamline design of the protective cover , safe, environmental and artistic.
8. The machine structure is scientific and reasonable ,intelligent control, high safe operation rate and convenient maintenance.

Technical-economic Index

Designed Output

2000-3000kg/h

Power

114.3 kW

Lint quality

meet or better than the national standard of the same grade cotton.

Noise

≤85dB(A)


Parameters

Pieces of saw

215片/Pcs

Diameter of saw

Φ406mm

Spacing between saws

14.8mm

Diameter of brush cylinder

Φ450mm

Dimensions(L*W*H)

3688X4720X3608.5(mm)

Structural weight

12000 kg
